Velocity Range
-240～240km/h
Tuned for Performance, Ready for Scale
Phase-Locked & Free-Running Chirp Modes
01
Silicon Photonics Integration
02
Ultra-Narrow Linewidth Output
03
Wideband Linear Frequency Sweep
04
Ultra-High Chirp Linearity
-
-
Velocity Precision(1б)
0.05m/s -
Detection Range
1-300(230m@10%) -
Detection Precision(1б)
3cm -
Frame Rate
10Hz -
FOV
120° x 25° -
Minimum Angular Resolution
0.1° x 0.08° -
Data Point
1.5M/s
Ultra-Narrow Linewidth
Long-Range, High-SNR Performance
Delivers < 100 kHz linewidth for ultra-low phase noise and high SNR. Enables long-range detection with millimeter-level accuracy in range and velocity.
Wideband Fast Chirp
High-Throughput Output
Supports up to 15 GHz sweep bandwidth with fast chirp rates. Generates millions of points per second for real-time, high-resolution sensing in dynamic environments.
Ultra-High Chirp Linearity
Fidelity That Scales
> 99.99% Chirp Linearity achieves exceptional chirp linearity for high-fidelity signal transmission and accurate demodulation. Reduces DSP correction load and improves system robustness.
Application
ADAS
Velocity Measurement solves the CORNER CASE in AEB, NOA Enhance the ride experience with LiDAR
Autonomous Driving
L3, or even L4 requirements for the sensor
Robot Tec
Resilient to Environmental Factors Improved Data Density and Resolution
Industry & Logistics
Resilient to Environmental Factors Improved Data Density and Resolution
Intelligent Traffic System
By providing accurate, real-time insights, FMCW LiDAR revolutionizes Intelligent Traffic Systems, optimizing safety, efficiency, and urban mobility.
